▲ NEX50-3ELM (with options) |
|
|
|
|
| |
|
|
|
| |
|
|
| |
 |
|
| |
These machines are used for molding thermosetting resin and BMC that excel in heat resistance, hardness, mechanical characteristics, and electrical property. These molded products are widely used for industrial electrical parts. These machines are also used for high-quality & high-productivity rubber injection and LIM moldings. We offer a variety of machines to meet your specific requirements. |
The high-precision temperature control permits easy molding. It offers more power and better operability than conventional machines. It possesses FA (factory automation) capability and is a machine of high-quality and high-productivity molding. |
The high-precision two-liquid metering unit and high kneadability screw materialize higher quality and producibility. Various material feeders including a cartridge and 200-liter drum are available. |
Similar to the thermosetting resin molding machine, this is designed to offer higher precision temperature control and greater power. We offer various types of material feeders that are peculiar to rubber molding, and it has a capability to add special mechanism/device according to the purpose. Our years of abundant experience and technologies will meet your variety of needs. |
|
| |
|
 |
|
| |
|
|
|
| |
|
|
We offer a variety of Liquid Injection Molding Machines other than listed on this website. These can be build on many different types of our machines (electric, hybrid, hydraulic, horizontal, vertical, etc…), injection sizes, and tonnages. Please contact us for more details. |
|
|
| |
|
|
| |
| |
|
Nissei has been actively engaging in developing new materials and moldings that are attracting wide attention in the industry, such as production of optical ferrules, eco-friendly biodegradable resin products, and more. |
|
| |
Nissei has developed a machine that materializes stable molding of high-precision/high-quality optical ferrules. A compete system consists of the material, mold, automatic alignment unit with gate cut functions, degreasing furnace, sintering furnace, and polishing machine, constructing an integrated production line for ferrules. |
|
| |
The biodegradable resins can be decomposed by micro organisms in the nature and returned to the soil. In order to solve the issue with material cost and physical property, direct blend molding method with inexpensive filler has been established. It materializes the reduction of production cost while improving the rigidity and decomposition rate. |
|
| |
The machine is equipped with abrasion/corrosion-proof screw and barrel in order to mold fine ceramics that are used as high-functional material, as well as coping with sintered material molding by metal powder. The machine permits mass production of products that have complicated shapes with high precision and repeatability. |
|
| |
As an anisotropic plastic magnet molding machine, it is equipped with the original magnetic field generator, materializing stable molding of products with high magnetomotive force. |
|
|
|
| |
|
|
| |
|
|
We offer a vent type molding machine that utilizes a sufficient degassing effect to ensure high-quality molding of highly hygroscopic resins, as well as various special molding machines that promote the recycling of crushed PET bottle materials. |
Vent Type Injection Molding Machine
The vent type molding machine is applicable to the molding of hygroscopic resins. We have paid special attention to the design of screw, barrel, and temperature control, which are vital to vent molding. Its simple structure materializes easy-to-use, fine, and stable temperature control. Thus, the standard specification is sufficient to achieve excellent vent effect and prevent vent-up, and its operation is as easy as that of general-purpose machines. |
Recycling Molding of PET Bottles (Vent Type)
In order to promote the collection of PET bottle and its recycle, Nissei has developed a recycle molding system equipped with the original material feeder, which can process non-crystalline crushed PET bottles without drying. This machine facilitates lowering running costs in many different fields. |
|
 |
| |
▲ Crushed PET bottles |
|
| |
|
|
|
| |
|
|
|
